Our company is a professional CNC machinery equipment manufacturer that has passed ISO 9001 quality management system certification. We strictly follow international quality management standards to ensure stable and reliable product quality.
Market Distribution
Our main markets cover Russia, Southeast Asia, and many other countries and regions around the world; We have a professional overseas sales team. At present, the annual sales volume is between 500 and 600 units, reaching an annual sales revenue of 5 million to 6 million US dollars which shows a year-on-year growth trend.
Company Strength
Our factory covers an area of about 3,000 square meters, equipped with four modern production lines and a total of about 60 employees, covering multiple functional departments such as raw material inspection, processing and manufacturing, surface treatment, finished product inspection and delivery. We have a complete production system and efficient operation management capabilities.
Our Services
We provide one-stop services including product consultation, technical parameters introduction and performance analysis, demand analysis, product recommendation and quotation, order processing logistics distribution installation commissioning after-sales technical support maintenance parts supply; we are committed to providing customers with comprehensive solutions.
|
X/Y/Z Axis motion positioning accuracy |
0.02/0.02/0.01mm-300mm |
0.025/0.025/0.01mm-300mm |
0.02/0.03/0.01mm-300mm |
|
X/Y/Z Axis motion positioning accuracy |
0.015/0.015/0.008mm-300mm |
0.015/0.020/0.008mm-300mm |
0.015/0.025/0.008mm-300mm |
|
X/Y/Z Axis working stroke |
1300/1350/200mm |
1300/2650/200mm |
1500/3050/200mm |
|
System screen size |
12 inches |
12 inches |
12 inches |
|
Table size |
1300*1350 |
1300*2650 |
1500*3050 |
|
Spindle to table distance |
50-350mm |
50-350mm |
50-350mm |
|
Maximum working load |
300kg |
400kg |
500kg |
|
Spindle power |
ISO25-3.02KW/BT30-4.5KW |
ISO25-3.0kw/BT30-4.5kw |
ISO25-3.0KW/BT30-4.5KW |
|
Spindle speed |
120-30000rpm(Motor spindle) 120-12000rpm(Mechanical main drawer) |
||
|
Shank specifications |
BT30(Motor spindle)/BT40(Mechanical main drawer) |
||
|
The type of tool magazine |
Servo sector magazine |
Servo sector magazine |
Servo sector magazine |
|
Tool magazine capacity |
10 |
||
|
X/Y/Z Fast movement speed |
15/15/15m/min |
15/15/15m/min |
15/10/15m/min |
|
Maximum cutting speed |
12m/min |
12m/min |
12m/min |
|
Drive system |
AC servo |
AC servo |
AC servo |
|
Operating voltage |
Triphasic380V/50HZ |
Triphasic380V/50HZ |
Triphasic380V/50HZ |
|
Air supply voltage |
≥0.6MPa |
≥0.6MPa |
≥0.6MPa |
|
The total weight of the machine |
3500kg |
4200kg |
5000kg |
Fine cut
For cutting to depths greater than twenty degrees into the material, an engraving and milling machine's specialized cutting head provides deep cuts.
Aesthetics
The main objective is to improve the visual aspect of the material without changing its overall structure.
High accuracy
Precise accuracy is one of the important characteristics of engraving and milling machines. The details can be gracefully designed on the machine.
Less material removal rates
Engraving and milling machines only remove little material preventing workpiece from any physical damage.
Metals
Including copper, aluminum and stainless steel, etc., to produce high-precision parts and decorations.
Plastics
Such as polystyrene, polyethylene and abs. The engraving and milling machine can produce various complex shapes and patterns on plastics.
Wood
Softwood, hardwood and cork can all be engraved. Exquisite wood carvings and furniture decorations can be produced.
1. Before operating the engraving and milling machine, be sure to read the operating instructions in detail and confirm that they are familiar with the performance of the machine. Those who are not familiar with the machine are strictly prohibited from operating the machine.
2. Before operating the engraving and milling machine, please read and understand the warning signs. Do not move or damage the warning signs installed on the machine. If the warning signs become blurred or removed, please replace them.
3. Before operating the engraving and milling machine, remove the tie, ring, watch and other jewelry, and roll the sleeves over the elbow; do not wear loose clothes, limit long hair, it is recommended to wear non-slip shoes or non-slip floor strips.
4. It is not allowed to wear gloves to operate the machine tool during work.
5. When using an engraving and milling machine, be sure to wear approved safety glasses/face shields.
6. Wear ear protectors (earplugs or earmuffs) when operating for a long time.
7. Be careful not to place obstacles around the machine tool, the working space should be large enough, and provide glare-free overhead lighting.
8. It is not allowed to use compressed air to clean machine tools, electrical cabinets and NC units.
Pre-sale services
Product consultation, introduction of technical parameters and machine performance.
In sales service
Requirement analysis, product introduction and quotation, order processing, logistics distribution, installation services
After-sale service
After sales technical support
Supply of repair parts
|
Packaging |
Wooden box, PE film |
|
Transportation methods |
Road transport, rail transport, sea transport, air transport |
As one of the most professional engraving and milling machine manufacturers and suppliers in China, we're featured by quality products and good price. Be free to wholesale discount engraving and milling machine in stock here and get quotation from our factory. Contact us for customized service.
